Key Features
- TQ HPR50 Motor: 50 Nm, 250 W motor with a 580 Wh battery. Compact, light and nearly silent giving you all the support you need for long, gruelling climbs.
- Carbon Fibre Frame: Lightweight, compliant & durable.
-
Shimano 12-Speed: Reliable shifting, with a wide range of gears for all-terrain – even the biggest of hills.
Full Specification
- Frame: OCLV Mountain Carbon, removable battery, high main pivot, idler pulley, angle-adjust headset, adjustable leverage rate, integrated frame protection, internal routing, magnesium rocker link, upper chain guide mount, 55 mm chainline, ABP, UDH, 148x12 mm thru axle, 170 mm travel
- Rear Shock: Fox Performance Float X, 2-position damper, 230 mm x 65 mm
- Fork: Fox Rhythm 38, Float EVOL air spring, GRIP damper, tapered steerer, 44 mm offset, Boost110, 15 mm Kabolt X axle, 170 mm travel
- Motor: TQ HPR50, 50Nm, 250W
- Battery: TQ 580Wh
- Controller: TQ
- Charger: TQ 4A charger
- Gear Shifters: Shimano XT M8100, 12-speed
- Chainset: E*thirteen E*spec, 32T alloy ring, 55 mm chainline, E*thirteen E*spec Plus, 160 mm length
- Rear Cassette: Shimano SLX M7100, 10-51T, 12-speed
- Chain: Shimano SLX M7100, 12-speed
- Rear Derailleur: ShimanoXT M8100, long cage
- Bottom Bracket:
- Pedals: Not supplied
- Rims: Bontrager TLR
- Front Hub: Bontrager Line Comp 30, 6-bolt, Boost110
- Rear Hub: Bontrager Line Comp 30, Boost148
- Front Tyre: Size: S Bontrager XR5 Team Issue, Tubeless Ready, Inner Strength casing, aramid bead, 60 tpi, 27.5 x 2.50", Size: M, L, XL Bontrager XR5 Team Issue, Tubeless Ready, Inner Strength casing, aramid bead, 60 tpi, 29x2.50"
- Rear Tyre: Bontrager XR5 Team Issue, Tubeless Ready, aramid bead, 120 TPI, 27.5x2.50"
- Brakes: Shimano 4-piston hydraulic disc, M6100 lever, M6120 calliper
- Handlebars: Bontrager Line, alloy, 35 mm, 27.5 mm rise, 780 mm width
- Handlebar Grips: Bontrager XR Trail Elite, nylon lock-on
- Headset:
- Stem: Bontrager Elite, 35 mm, 0-degree, 35 mm length
- Saddle: Bontrager Verse P3, chromoly rails
- Seatpost: Size: S Bontrager Line Dropper, 100mm travel, MaxFlow, internal routing, 34.9 mm, 310mm length Size: M, L, XL Bontrager Line Dropper, 170 mm travel, MaxFlow, internal routing, 34.9 mm, 450 mm length
- Accessories:
-
Weight: M - 20.38 kg / 44.94 lbs (with TLR sealant, no tubes). Weight Limit - This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.
Bike and frame weights are based on pre-production painted frames at time of publication. Weights may vary in final production.
