eBikes by their very nature can in the future require aftermarket updates and support. This cannot be supplied by All Terrain Cycles at distance; if required the work would have to be obtained from your local Brand Dealership, possibly at extra cost to yourself.
Your eBike will be delivered built, set up and updated.
Minimum personal assembly is required.
A new breed of trail bike that blends power, performance and flat-out fun. With its lightweight composite frame, plush suspension and new motor technology, you’ll never want the ride to end.
Key Features
- Powerful and Responsive: SyncDrive Pro motor with 85Nm of torque creates powerful pedalling assistance even at low speeds. Lightweight, stiff Advanced-grade composite frame with 140mm of Maestro rear suspension travel and 150mm up front delivers confident handling and control on rough trails.
- Adaptable to the Terrain: Flip chip feature lets you change the head tube and seat tube angles, along with the bottom bracket height, to fine-tune handling for varying trail conditions and individual riding style. You can choose the low position for fast, aggressive terrain, or high for a more XC-oriented rider position.
- Clean Cockpit: RideControl Go top tube integrated multi-function on/off button and RideControl Ergo 3 handlebar-mounted remote, which can be mounted on either grip, offer user-friendly controls and an uncluttered cockpit design.
Full Specification
- Frame: Advanced-grade composite frame, Advanced-grade rear triangle, Advanced forged composite upper rocker, 140mm Maestro suspension system, 'Boost' 148x12 UDH rear axle, Giant EnergyPak Plus Range Extender Compatible
- Fork: Fox 36 Float Performance E-Tuned, 29er, 150mm travel, 44mm offset, Grip 3-position Micro Adjust damper, Kabolt-X 110
- Rear Shock: Fox DPS Performance, EVOL Large Volume sleeve, 3-position Lever, 185x52.5mm Trunnion mount, custom tuned
- Motor: Giant SyncDrive Pro2 85Nm, powered by Yamaha, PedalPlus 6-Sensor technology
- Controller: Giant RideControl Ergo3, grip integrated remote
- Display: Giant RideControl GO, frame integrated LED console Optional wireless ANT+ display
- Battery: Giant EnergyPak 800Wh, 22700 Lithium cell technology, Aluminium casing with highest safety standard (EN50604), CO2 Neutral production Giant EnergyPak Plus 250 range extender compatible
- Gear Shifters: Shimano Deore SLX
- Chainset: Praxis Wavetm 36T Cold Forged 4130 premium steel Praxis e-Cadet+ custom forged crankarm set (S:160mm, M/L: 165mm, XL:170mm)
- Rear Cassette: Shimano CS-M6100, 10-51T, 12-speed
- Chain: KMC e.12 Sport, NP/NP, e-bike optimised
- Front Derailleur: MRP HD2 co-moulded chain guide
- Rear Derailleur: Shimano Deore SLX, 12-speed, Shadow+
- Bottom Bracket: Giant Integrated
- Pedals: Flatpedal
- Rims: Giant AM 29", Tubeless ready, 30mm inner width, e-bike optimised
- Front Hub: Shimano MT410, Boost, Center-Lock,110x15
- Rear Hub: 148x12mm Micro-Spline Drive Body Thru-axle
- Front Tyre: Maxxis Minion DHF 29x2.6" foldable, Tubeless, EXO+, 3C MaxxTerra
- Rear Tyre: Maxxis Dissector 29x2.6" Foldable, Tubeless, EXO+, 3C MaxxTerra
- Brakes: Shimano SLX, BR-M7120, 4-piston, hydraulic disc, 203mm
- Handlebars: Giant Contact 35 Trail, 35x780mm
- Handlebar Grips: Giant Tactal Pro-E, single lock-on
- Stem: Giant Contact SL 35
- Saddle: Giant Romero, Neutral
- Seatpost: Giant Contact Switch, dropper, 30,9mm (S:125/M:150/ L&XL:170)
- Accessories: Tubeless kit (liquid, valves, levers, manual, tool) Inner tube supplied
- Weight: N/A
We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.
Bike and frame weights are based on pre-production painted frames at time of publication. Weights may vary in final production.
