TREK FETCH+ 4 ELECTRIC CARGO BIKE 2025 LAVA
Product Details - Trek Fetch+ 4 Electric Cargo Bike 2025 Lava
Product Details - Trek Fetch+ 4 Electric Cargo Bike 2025 Lava
Due to the size of this bike, it may not be possible to deliver this to you depending upon your location. Please check prior to ordering to avoid disappointment.
eBikes by their very nature can in the future require aftermarket updates and support. This cannot be supplied by All Terrain Cycles at distance; if required the work would have to be obtained from your local Brand Dealership, possibly at extra cost to yourself.
Your eBike will be delivered built, set up and updated.
Minimum personal assembly is required.
The Fetch+ 4 is an electric cargo box bike that helps you carry a lot, connect with your kids and even replace your car. Confidently carry up to five children (max. box weight of 80 kg) thanks to the powerful boost of the Bosch smart system and best-in-class handling and stability. This bike is designed to grow with your family, and offers multiple configuration options for carrying your most precious cargo as your needs shift over time.
Key Features
- Fetch dual-pivot kickstand: Keeps the bike stable and steady while loading and unloading and is super easy to engage and disengage.
- Bosch Performance Line CX Smart System Motor: Powerful acceleration combined with compact size.
- Hydraulic disc brakes: Strong stopping power for when you need it most.
- Frame: High performance hydroformed alloy, low-step, Removable Integrated Battery, internal cable routing, Motor Armor, post-mount disc, 148x12 thru axle
- Fork: SR Suntour Mobie A32, 50mm travel
- Motor: Bosch Performance Line CX, smart system, magnesium motor body, 85 Nm, 25 km/h max assist
- Battery: Bosch PowerTube 750Wh, smart system
- Charger: Bosch 4A, 230V, smart system
- Controller: Bosch BSP3200 smart phone grip
- Gear Shifters: Enviolo Pro Manual Controller twist shift display
- Chainset: ProWheel alloy, 170mm length
- Chainrings: Gates CDX, 50T
- Rear Cassette: Gates CDX, 22 T, steel
- Chain/Belt: Gates CDX Belt, 128T
- Front Derailleur: N/A
- Rear Derailleur: Enviolo CVP Heavy Duty, 6-bolt, 40T spline
- Bottom Bracket: Integrated with motor
- Pedals: Bontrager City pedals
- Rims: Alloy double-walled, 32-hole
- Front Hub: Formula DC-71 alloy, sealed bearing, 6-bolt, 15x100mm thru axle
- Rear Hub: Enviolo CVP Heavy Duty, 6-bolt, 40T spline
- Front Tyre: Schwalbe Pick-Up, Addix E-Compound, ECE-R75 approved, wire bead, 20x2.15"
- Rear Tyre: Schwalbe Pick-Up, Addix E-Compound, ECE-R75 approved, wire bead, 20x2.15"
- Brakes: HD-T737 4-piston hydraulic disc
- Handlebars: Alloy, 31.8mm clamp, 25mm rise, 630mm width
- Handlebar Grip: Bontrager Satellite Elite, alloy lock-on
- Headset: FSA Integrated, sealed cartridge bearing, 1-1/8" top, 1.5" bottom
- Stem: Bontrager alloy, 31.8 mm clamp, 35-degree, 90 mm length
- Seatpost: TranzX JD-YSP28PLQ, 200mm travel, internal routing, 31.6 mm
- Saddle: Bontrager Boulevard
- Accessories: Herrmans MR8, 180 lumen LED, Trelock LS614 with brake light, Fetch custom double leg kickstand, Trek Fetch custom mudguard, MIK HD rear pannier rack, frame lock, 2 Trek child seats
- Weight: 75kg
- Max Weight Limit: 250 kg (Consisting of Rider, Bike and Cargo)
We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.
Bike and frame weights are based on pre-production painted frames at time of publication. Weights may vary in final production.
How we Build & Pack Your Bike
How we Build & Pack Your Bike
Aftercare
Aftercare
At All Terrain Cycles, we want you to ride with confidence every time. To ensure your bike or e-bike stays in peak condition, here are some essential safety and maintenance tips.
Bicycle Safety
Always wear a helmet – Safeguard against head injuries by using a properly fitted, safety-certified helmet.
Perform pre-ride checks – Before each ride, verify that brakes, tyres, and gears are in good working order.
Stay visible – Utilise lights and reflective gear when cycling in low-light conditions.
Follow road rules – Ride responsibly and remain aware of your surroundings.
Aftercare for Your New Bike Initial Check-Up (First 50-100 miles)
Gear Adjustment – New cables may stretch slightly; have a qualified mechanic check and adjust them.
Brake & Wheel Check – Inspect brakes for wear and ensure wheels are aligned properly.
Lubrication – Apply chain oil and check bolt tightness to maintain smooth performance.
Tyre Pressure – Regularly monitor to prevent flats and enhance efficiency.
Routine Maintenance (Every Few Weeks)
Chain Care – Clean and lubricate your chain to minimise wear and prolong its life.
Brake Safety – Check brake pads and responsiveness before each ride.
Tyre Inspection – Look for punctures and ensure correct air pressure.
Handlebar & Stem Alignment – Confirm they are tight and secure to prevent instability.
Frame Safety Check – Look for any signs of damage or cracks.
Professional Check-Ups
Have your bike serviced at least once a year, or more frequently if you ride often.
Aftercare for Your New Electric Bicycle (e-Bike) Initial Check-Up (First 50-100 miles)
Battery Care – Fully charge your battery (if required) before the first ride and store it in a dry, moderate-temperature environment.
Avoid Overcharging – Unplug the charger once fully charged to extend battery life.
Routine e-Bike Maintenance (Every Few Weeks)
Motor Inspection – Listen for unusual noises and ensure smooth operation.
Battery & Connection Checks – Inspect cables and connectors for dirt, moisture, or damage.
Seasonal e-Bike Maintenance
Check Electrical Components – Ensure wires and connections are clean and secure.
Professional Servicing – Have your e-bike inspected at least once a year or every 500-1000 miles for optimal performance.
By following these aftercare guidelines, you’ll help ensure that your bicycle runs smoothly, lasts longer, and remains a joy to ride. Stay safe and enjoy the ride!
If you have any problems or concerns: Contact All Terrain Customer Services on 01274 588488 or email sales@allterraincycles.co.uk
