CUBE REACTION HYBRID RACE 750 E-MTB BIKE 2023 OLIVE´N´GREEN

Skip to product information
1 of 8

Product Details - Cube Reaction Hybrid Race 750 E-mtb Bike 2023 Olive´n´green


eBikes by their very nature can in the future require aftermarket updates and support. This cannot be supplied by All Terrain Cycles at distance; if required the work would have to be obtained from your local Brand Dealership, possibly at extra cost to yourself.

Your eBike will be delivered built, set up and updated.

Minimum personal assembly is required.


With its high-capacity Bosch PowerTube battery, fourth-generation Bosch CX power and the slick shifting and wide range of Shimano's 1x12 XT gears, the CUBE Reaction Hybrid Race has what you need to broaden your horizons and take your riding to the next level.


Open 360° view


Frame sizes S (15") come with 27.5" wheels, sizes M (17"), L (19"), XL (21") and XXL (23") are 29ers.

Key Features

  • 250W Bosch Motor: Most reliable pedal-assist motor in e-bike industry, capable of sustaining speeds up to 25 km/h
  • Hydraulic Disc Brakes: Reliable braking performance to keep you in control, whatever the weather.
  • 12 Shimano Gears: Wide range of gears suitable for a range of terrain, with the simplicity of a single shifter.

Specification

  • Frame: Aluminium Superlite, Gravity Casting, Agile Ride Geometry, 1.5 Headtube, Boost 148, Full Integrated Battery, Advanced Internal Cable Routing, Kickstand/Fender/Carrier Mounting Points
  • Fork: RockShox Judy Silver TK Air, Tapered, 15x110mm, eMTB Approved, 120mm, Lockout (EE: 100mm)
  • Motor: Bosch Drive Unit Performance CX Generation 4 (85Nm) Cruise (250Watt), Smart System
  • Battery: Bosch PowerTube 750
  • Controller: Bosch LED Remote
  • Charger: Bosch 4A
  • Gear Shifters: Shimano Deore SL-M6100-IR, Direct Attach, Rapidfire-Plus
  • Chainset: ACID E-Crank, 38T, 175mm
  • Chainrings: 38T
  • Rear Cassette: Shimano Deore CS-M6100, 10-51T
  • Chain: Shimano CN-M6100
  • Front Derailleur: N/A
  • Rear Derailleur: Shimano XT RD-M8100-SGS, ShadowPlus, 12-Speed
  • Pedals: ACID PP MTB
  • Rims: CUBE EX30, 32H, Disc, Tubeless Ready
  • Front Hub: Shimano HB-MT400-B, 15mm, Boost, Centerlock
  • Rear Hub: Shimano FH-MT400-B, 12mm, Boost, Centerlock
  • Front Tyre: Schwalbe Smart Sam, Active, 2.6
  • Rear Tyre: Schwalbe Smart Sam, Active, 2.6
  • Brakes: Shimano BR-MT420, Hydr. Disc Brake (203/203)
  • Handlebars: CUBE Rise Trail Bar Pro, 740mm
  • Grips or Bar Tape: ACID React Pro / EE: ACID Hybrid Perform
  • Headset: ACROS AZF-1035, ICR (Integrated Cable Routing), BlockLock 120°, Top Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm)
  • Stem: CUBE Performance Stem E-MTB, 31.8mm
  • Saddle: Natural Fit Sequence
  • Seatpost: CUBE Performance Post, 30.9mm
  • Weight: 24.1Kg

We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.

Weights are based off pre-production products at time of publication. Weights may vary in final production.

How we Build & Pack Your Bike

Aftercare

At All Terrain Cycles, we want you to ride with confidence every time. To ensure your bike or e-bike stays in peak condition, here are some essential safety and maintenance tips.

Bicycle Safety

Always wear a helmet – Safeguard against head injuries by using a properly fitted, safety-certified helmet.

Perform pre-ride checks – Before each ride, verify that brakes, tyres, and gears are in good working order.

Stay visible – Utilise lights and reflective gear when cycling in low-light conditions.

Follow road rules – Ride responsibly and remain aware of your surroundings.

Aftercare for Your New Bike Initial Check-Up (First 50-100 miles)

Gear Adjustment – New cables may stretch slightly; have a qualified mechanic check and adjust them.

Brake & Wheel Check – Inspect brakes for wear and ensure wheels are aligned properly.

Lubrication – Apply chain oil and check bolt tightness to maintain smooth performance.

Tyre Pressure – Regularly monitor to prevent flats and enhance efficiency.

Pedals - Ensure pedals are still tight and correctly fitted.

Routine Maintenance (Every Few Weeks)

Chain Care – Clean and lubricate your chain to minimise wear and prolong its life.

Brake Safety – Check brake pads and responsiveness before each ride.

Tyre Inspection – Look for punctures and ensure correct air pressure.

Handlebar & Stem Alignment – Confirm they are tight and secure to prevent instability.

Frame Safety Check – Look for any signs of damage or cracks.

Pedals - Ensure pedals are still tight and correctly fitted.

Professional Check-Ups

Have your bike serviced at least once a year, or more frequently if you ride often.

Aftercare for Your New Electric Bicycle (e-Bike) Initial Check-Up (First 50-100 miles)

Battery Care – Fully charge your battery (if required) before the first ride and store it in a dry, moderate-temperature environment.

Avoid Overcharging – Unplug the charger once fully charged to extend battery life.

Pedals - Ensure pedals are still tight and correctly fitted.

Routine e-Bike Maintenance (Every Few Weeks)

Motor Inspection – Listen for unusual noises and ensure smooth operation.

Battery & Connection Checks – Inspect cables and connectors for dirt, moisture, or damage.

Pedals - Ensure pedals are still tight and correctly fitted.

Seasonal e-Bike Maintenance

Check Electrical Components – Ensure wires and connections are clean and secure.

Professional Servicing – Have your e-bike inspected at least once a year or every 500-1000 miles for optimal performance.

By following these aftercare guidelines, you’ll help ensure that your bicycle runs smoothly, lasts longer, and remains a joy to ride. Stay safe and enjoy the ride!

Read our full advice

If you have any problems or concerns: Contact All Terrain Customer Services on 01274 588488 or email sales@allterraincycles.co.uk
