AMFLOW PL CARBON PRO 800Wh FULL SUSPENSION eMTB BIKE 2025 COSMIC BLACK

Pre Order Bikes Arriving in Late April

eBikes by their very nature can require aftermarket updates and support. This cannot be supplied by All Terrain Cycles at distance; if required the work would have to be obtained from your local Brand Dealership, possibly at extra cost to yourself.

Your eBike will be delivered built, set up and updated in two boxes.

Minimum personal assembly is required.

Designed and manufactured by DJI, the Avinox Drive System is seamlessly integrated into Amflow PL, infusing the type of cutting-edge hardware and software that has made DJI an industry leader in drones and camera stabilization technology.

The Avinox Drive Unit features a compound planetary gearset with an industry-leading power-to-size ratio.

The durable, high-strength polymer material inside the Drive Unit effectively suppresses noise during high-speed gearbox operation. With multiple precision sensors built-in, combined with advanced DJI algorithms, it provides a strong, smooth assistance for a wide range of scenarios and conditions.

Please note that pedals are not included!

Key Features Amflow PL Carbon Pro eMTB Bike 2025

• With its unrivalled combination of power, range, weight, and intelligent features, this groundbreaking eMTB is built for the trailblazers.
• A full-power eMTB with a stunningly lightweight body. Meticulously designed and crafted to deliver the ultimate ride.
• Amflow PL's ultra-light carbon fiber frame weighs just 2.27 kg, for breathtaking speed and agility.

Full specification

• Frame: Amflow PL Carbon Frame
• Fork: FOX 36 Factory 160mm travel, GRIP Damper, 15×110mm, 44mm rake
• Rear Shock: Fox Float X Factory, Trunnion (185×55mm), custom tune, EVOL Air sleeve, 2-position lever w/ LSC adjustment
• Gear Shifters: SRAM AXS Pod Controller
• Chainset: DJI Avinox SL Crank (M/L: 155mm; XL/XXL: 160mm)
• Rear Cassette: SRAM XG-1295 Eagle, 10-52T
• Chain: SRAM X0 Eagle Transmission Flattop Chain
• Front Derailleur: N/A
• Rear Derailleur: SRAM X0 Eagle Transmission Derailleur w/ power cable
• Pedals: not included
• Rims: Carbon, 29'', 30mm internal width, 28H, tubeless ready
• Spokes: SAPIM E-Light Straightpull
• Front Hub: Alloy, 2 sealed cartridge bearings, 15×110mm thru-axle, 28h, straight-pull, 6-bolt
• Rear Hub: Alloy, 4 sealed cartridge bearings, 148×12mm thru-axle, 28h, straight-pull, 6-bolt, 78T
• Front tyre: Maxxis Assegai, MaxxTerra 29×2.5" WT 3C EXO E-25 TLR
• Rear tyre: Maxxis Dissector, Maxxterra 29×2.4" WT 3C EXO+ E-25 TLR
• Brakes: Magura MT7 Pro hydraulic disc brake, HC lever, 4-piston caliper, 203mm Storm HC Rotor (front and rear)
• Handlebars: Amflow Enduro Carbon Handlebar, 25mm rise, 800mm wide, 5-degree upsweep, 9-degree backsweep
• Grips: Amflow Enduro Grips
• Stem: Amflow Enduro Stem, One-piece CNC
• Saddle: Selle Royal SRX Plus
• Seatpost: Fox Transfer Factory, Travel adjustable in 5mm(M: 125-150mm, L/XL: 155-180mm, XXL: 180-210mm)
• Display: Avinox Screen: 2-inch OLED Control Display
• Battery: Avinox Integrated Battery: 800Wh
• Charger: Avinox Fast Charger: 12A/508W
• Engine: Avinox M1 Drive Unit: 105 N·m
• Accessories: Quick Start Guide, Torque Wrench (3~25 N·m, Hex 2/3/4/5/6mm, Torx® 25), Shock Pump, Front and Rear Lights.

We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.

Bike and frame weights are based on pre-production painted frames at time of publication. Weights may vary in final production.

At All Terrain Cycles, we want you to ride with confidence every time. To ensure your bike or e-bike stays in peak condition, here are some essential safety and maintenance tips.

Bicycle Safety

Always wear a helmet – Safeguard against head injuries by using a properly fitted, safety-certified helmet.

Perform pre-ride checks – Before each ride, verify that brakes, tyres, and gears are in good working order.

Stay visible – Utilise lights and reflective gear when cycling in low-light conditions.

Follow road rules – Ride responsibly and remain aware of your surroundings.

Aftercare for Your New Bike Initial Check-Up (First 50-100 miles)

Gear Adjustment – New cables may stretch slightly; have a qualified mechanic check and adjust them.

Brake & Wheel Check – Inspect brakes for wear and ensure wheels are aligned properly.

Lubrication – Apply chain oil and check bolt tightness to maintain smooth performance.

Tyre Pressure – Regularly monitor to prevent flats and enhance efficiency.

Routine Maintenance (Every Few Weeks)

Chain Care – Clean and lubricate your chain to minimise wear and prolong its life.

Brake Safety – Check brake pads and responsiveness before each ride.

Tyre Inspection – Look for punctures and ensure correct air pressure.

Handlebar & Stem Alignment – Confirm they are tight and secure to prevent instability.

Frame Safety Check – Look for any signs of damage or cracks.

Professional Check-Ups

Have your bike serviced at least once a year, or more frequently if you ride often.

Aftercare for Your New Electric Bicycle (e-Bike) Initial Check-Up (First 50-100 miles)

Battery Care – Fully charge your battery (if required) before the first ride and store it in a dry, moderate-temperature environment.

Avoid Overcharging – Unplug the charger once fully charged to extend battery life.

Routine e-Bike Maintenance (Every Few Weeks)

Motor Inspection – Listen for unusual noises and ensure smooth operation.

Battery & Connection Checks – Inspect cables and connectors for dirt, moisture, or damage.

Seasonal e-Bike Maintenance

Check Electrical Components – Ensure wires and connections are clean and secure.

Professional Servicing – Have your e-bike inspected at least once a year or every 500-1000 miles for optimal performance.

By following these aftercare guidelines, you’ll help ensure that your bicycle runs smoothly, lasts longer, and remains a joy to ride. Stay safe and enjoy the ride!
