The world’s most successful downhill pedal is now available in a premium edition featuring titanium wings and dual-chamfered edges to minimize weight and maximize performance. The Mallet DH 11 is designed and engineered for the rider who wants the best of the best, and nothing less.

Features

• Titanium wings to reduce weight
• Double anodized black and gold colourway
• Wide 57mm q-factor for stability at speed
• Integrated traction pad technology to customize and optimize the shoe/pedal interface
• Concave platform for secure foothold
• 8 adjustable pins per side for grip
• ribbed body for better traction when unclipped
• Dual chamfered edges to reduce weight and rock-strikes
• Hex alloy endcap for durability
• 4-sided entry / superior mud shedding
• Customizable float & release angle
• Premium bearings & double seal system

Specification

• Spindle material: Forged scm 435 chromoly steel
• Body material: 6061-T6 aluminium
• Wing material: 6al / 4v titanium
• Spring material: 300 series stainless steel
• Release angle: 15° / 20°
• Max rider weight: No restriction
• Q-factor: 57mm
• Inner bearing type: Igus LL-glide bearing
• Outer bearing type: Enduro cartridge bearing
• Endcap: Hex alloy
• Cleat: Premium brass cleats with shims included

Weight

• 445 g

Contents

• 1 pair of CrankBrothers Mallet DH 11
• 1 pair of cleats
